Required Tools and Equipment
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l SH12 infrastructure modules
o
CEM-2
o
ECM-2
o
Three FTM-2s
o
One to four PSM-DCs (depending on your redundancy, load sharing configuration)
l SH4R infrastructure modules
o
CEM-4
o
ECM-2
o
Two FTM-4s
o
One to three PSM-AC4s (depending on your redundancy, load sharing
configuration)
l Torx T10 screwdriver
l Installation Overview — SH12 and SH4R Shelves
l Infrastructure Modules
l Handling Modules
Installing the CEM
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module have been properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the CEM with the faceplate toward you and the levers extended.
3. Align the CEM edges with the guides of the shelf slot.
4. Lift out on the levers and gently apply pressure to the bottom of the faceplate while
pushing the module into the slot.
5. Push on the faceplate to fully seat the module.
6. Press down on the locking levers to secure the module and connect it to the
backplane. The module is completely inserted when its faceplate is flush with the
shelf panels.
7. When the CEMis inserted completely, hand tighten the thumb screws to prevent
inadvertent dislodging.
8. Use a Torx T10 screwdriver to gently tighten the thumb screws. Do not overtighten.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 215
