FD-128D
Signal Path
The following figure provides a simplified functional block diagram illustrating the FD-
128D signal path.
l Overview
l Features
l Interfaces
Specifications
The following tables provide the optical specifications from the client port to the network
port.
Insertion loss Maximum:<9.5 dB
Passband width >150 pm
Table 37: Optical Characteristics — Multiplexer
Insertion loss Maximum: 9.5 dB
Passband width >150 pm
Table 38: Optical Characteristics — Demultiplexer
