Unpacking a 4Uor 1UShelf
Each shelf comes with two 19-inch rack-mounting brackets preinstalled
and each unoccupied shelf slot is filled with the appropriate slot cover.
15. Save the packaging material until the operational checkout of the FSP 3000 C
equipment is complete. Storing all the shipping boxes and packaging material
enables the FSP 3000 C components to be repacked for a possible transport to
another installation site or to be returned for a needed repair.
l Shipment Contents —SH12
l Shipment Contents — SH4R
l Qualified Personnel Warning
l Shelf Lifting and Moving Guidelines
l Handling Equipment Precautions and Guidelines
l Electrostatic Discharge Damage Prevention and Warning
Unpacking a 4Uor 1UShelf
In this procedure, 4U shelf refers to the FD-128D. For unpacking
procedures for the SH4R, see Unpacking the SH12 and SH4R Shelves .
1. Attach a ground strap to your wrist and snap the ground wire to the wrist band. Insert
the ground plug into a grounded ESD jack.
2. Inspect the shipping boxes for evidence of damage during shipment. Claims for
damage during shipment must be asserted promptly with the transportation company
involved. If any damage or other signs of mishandling are evident, inform both the
freight carrier and ADVA Optical Networking before unpacking. Your freight carrier
can provide you with the procedures necessary to file a claim for damages.
3. Move the shipping box to a staging area as close to the installation site as possible,
where you have enough room to remove the shelf and components from the boxes.
Make sure that the shipping box has been in the installation location for a
minimum period of 24 hours to avoid thermal shock and surface
condensation when unpacking.
4. Open the shipping box:
a. Use a utility knife or scissors to cut open the adhesive tape. Pay attention not to
damage the flaps.
b. Lift the flaps toward you so that the box is opened completely.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 179
