Required Tools and Equipment
Chapter 17
Installing the Mounting Brackets
The FSP 3000 C shelves come with the 19-inch mounting brackets preinstalled. To
install the shelves in a 23-inch or ETSI rack, the 19-inch mounting brackets need to be
removed and the appropriate mounting brackets installed.
Required Tools and Equipment 183
Installing the Mounting Brackets on the SH12 and SH4R Shelves 184
Installing the Mounting Brackets on a 4U Shelf 186
Installing the Mounting Brackets on a FMT/1HU Shelf 187
The SH4R does not support an ETSIrack installation.
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Suitable grounded surface or a static-dissipative mat
l Appropriate mounting bracket pair for your configuration (19-inch, 23-inch, or ETSI)
with screws
l Torx T10 screwdriver (for the fixing bracket screws — SH12)
l Torx T20 screwdriver
For the SH4R, the 23-inch mounting brackets are not included with the
shelf and need to be ordered separately.
l Installation Overview — SH12 and SH4R Shelves
l Installation Overview — 4U Shelf
l Racks
l Accessories
