Adva FSP 3000 - Interfaces; Client Interface; Monitor Interface

FD-48E
o
Two bi-directional monitor ports for input (N-R) and output (N-T)
o
Two-color module (P) LED
o
Traffic alarm summary LED
l Ultra-fast transient suppression
l Is field replaceable
l Has front-accessible ports and connectors
l Is transport protocol independent
l Interfaces
l Signal Path
l Client Port Channel Assignments
l Handling Modules
l Electrostatic Discharge Damage Prevention and Warning
Interfaces
Client Interface 76
Monitor Interface 76
Network Interface 77
l Overview
l Port Pinouts
l Specifications
Client Interface
Number of client ports 48 Tx and 48 Rx
Type of client interface Bi-directional optical
Optical connector MPO24
Fiber type SM G.652
Monitor Interface
Number of monitor ports 2
Type of monitor interface Bi-directional for input (Mon N-R) and output (Mon N-T)
Optical connector LC/PC
Fiber type SM G.652
76 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
