Supported Rack Requirements
Chapter 11
Racks
Supported Rack Requirements 142
Building Structure Connection for Rack 145
Clearance Requirements 145
Supported Rack Requirements
The following tables detail the supported racks and cabinets for the SH12 and SH4R. In
the tables, the shelf column creates a category for each of the installation features.
Shelf
Supported
Installation
Features
19-inch 23-inch
ETSI 300-mm
Depth
ETSI 600-mm
Depth
SH12 (cables
w/MPO
connectors)
Two-post rack Supported Supported Supported Supported
Four-post rack Supported
1
Supported
1
Supported
1
Supported
1
Rack depth ≥400 mm
2
≥300 mm 300 mm 600 mm
Back-to-back racks Supported Supported Supported N/A
SH12 (cables
w/LC
connectors)
Two-post rack Supported Supported Supported Supported
Four-post rack Supported
1
Supported
1
Supported
1
Supported
1
Rack depth ≥400 mm
2
≥300 mm 300 mm 600 mm
Back-to-back racks Supported Supported Supported N/A
SH4R (cables
w/MPO
connectors)
Two-post rack Not supported Not supported Not supported Not supported
Four-post rack Supported Supported Not supported Not supported
Rack depth 600 to 1000 mm 600 to 1000 mm Not supported Not supported
SH4R (cables
w/LC
connectors)
Two-post rack Not supported Not supported Not supported Not supported
Four-post rack Supported Supported Not supported Not supported
Rack depth 600 to 1000 mm 600 to 1000 mm Not supported Not supported
Table 61: Open Rack Installations
