Fiber Optic Cables and Accessories
Fiber Optic Cables and Accessories
Patch Cables 163
Breakout Cables 164
To ensure faultless operation of the FSP 3000 C system, use only
fiber-optic cables released and provided by ADVA Optical
Networking. Fiber-optic cables other than ones released and provided
by ADVA Optical Networking may not be compatible with FSP 3000
C modules and interoperability cannot be guaranteed.
l Cabling Diagram with 48Optical Filter Channels
l Cabling Diagram with 128Optical Filter Channels
l Handling Fiber-Optic Cables
l Laser and LED Safety Guidelines and Warnings
Patch Cables
The following table details the patch cables available from ADVA Optical Networking.
These cables are used to connect the ECM-2 and the traffic modules.
Item Description
Sales Item
Number
Optical
Connectors
Fiber Type
Overall
Length
J/SM/LC/DUP/0300 1051002497 LC(duplex) Single-mode
3 m (9.84
ft)
J/SM/LC/DUP/0500 1051002495 LC(duplex) Single-mode
5 m (16.40
ft)
J/SM/LC/DUP/1000 1051002498 LC(duplex) Single-mode
10 m
(32.81 ft)
J/OM3/MPO12/0300 1051002616 MPO12
Multimode
50um OM3
3 m (9.84
ft)
J/OM3/MPO12/1000 1051002617 MPO12
Multimode
50um OM3
10 m
(32.81 ft)
J/SM/MPO12/0300 1051002621 MPO12 Single-mode
3 m (9.84
ft)
J/SM/MPO12/1000 1051002622 MPO12 Single-mode
10 m
(32.81 ft)
l Cabling Diagram with 48Optical Filter Channels
l Cabling Diagram with 128Optical Filter Channels
l Handling Fiber-Optic Cables
l Laser and LED Safety Guidelines and Warnings
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 163
