CEM-2
Specifications 43
Overview
The CEM-2 incorporates fan control, LED signaling and alarm LED control, integrated
utility feature, and ports for managing passive shelves.
The CEM-2 acts as the controller for the FTM-2, increasing and decreasing the fan speed
according to a set of input parameters from several different sensors. The main sensor is
the temperature sensor on the CEM-2 and additional sensors on each card and module
are considered.
It is installed under the fan modules in the SH12.
Figure 12: CEM-2 Faceplate
The External I/O interface and USBports are supported in a future
release. The timing ports (BITS1, BITS2), ToD/PPS port, 10MHz clock
connector, and PPS connector are supported in a future release, in
conjunction with timing modules.
Parameter Value Notes
Sales item number 1063800022-01
Release introduced Release 1.1
Compatible shelves SH12
Width 436.8 mm (17.2 in.)
Height 40 mm (1.6 in.)
Weight 1.1 kg (2.4 lbs)
Power consumption 9 W Typical
20.5 W Maximum
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 6: General Information — CEM-2
42 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
