Cable Management Best Practices
Chapter 13
Cables
Cable Management Best Practices 153
Grounding Cables 154
Power Cables 155
Serial and Ethernet Cables 160
IEEE 1394 Interface Cable 162
Fiber Optic Cables and Accessories 163
CAUTION
To ensure your safety, as well as the warranty, reliability and
compatibility of your FSP 3000 C system, use original ADVA parts and
components only.
Cable Management Best Practices
Use the following guidelines when trying to manage your FSP 3000 C cables:
l Whenever possible, use cable managers to secure excess cables.
l Before storing excess cable, use hook-and-loop bands or cable ties to loop and retrain
it (cable ties should never be used on fiber-optical cables).
o
Recommended hook-and-loop band specifications: 10 mm, black
o
Recommended cable tie specifications: 100 mm x 2.5 mm, black
l To ensure proper cooling of the equipment, ensure that excess cable does not impede
the airflow.
l Leave an appropriate amount of slack at end cable end.
l Ensure that fiber-optic cables have a minimum bend diameter of 70 mm.
l If you are using breakout cables, the breakout point must be outside the shelf(such as
in a fiber management tray).
Because there can be many fiber-optic cables, it is important to keep them organized. If
you do not use your rack posts for fiber management, ADVA Optical Networking strongly
recommends using the FMT/1HU.
