Installing the Mounting Brackets on a FMT/1HU Shelf
Save the remaining mounting brackets and packaging material for future
use.
l Installation Overview — 4U Shelf
l Site Preparation Checklist
Installing the Mounting Brackets on a
FMT/1HU Shelf
This procedure assumes that:
l The shelf has been unpacked and inspected;
l It is damage-free;
l The shelf is on a static-dissipative mat; and
l You want to install the shelf in a 23-inch or ETSI rack format. The
FMT/1HU shelf ships with the 19-inch brackets preinstalled.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Use the Torx T20 screwdriver to remove the two screws attaching the 19-inch
bracket to the shelf. Set aside the screws and bracket.
3. Place the appropriate 23-inch or ETSI mounting bracket on one side of the shelf in the
correct position.
4. Use the Torx T20 screwdriver and the two screws to attach the appropriate mounting
bracket to one side of the shelf.
5. Repeat this procedure for the other mounting bracket.
Save the remaining mounting brackets and packaging material for future
use.
l Installation Overview — 1U Shelf
l Site Preparation Checklist
