Required Tools and Equipment
Chapter 24
Installing the Traffic Modules and
Pluggable Transceivers
Required Tools and Equipment 220
Installing a Traffic Module 221
Installing a QSFPPluggable Transceiver 222
Use care when installing modules in a shelf. Ensure the modules are
properly aligned with the appropriate slot guides. Do not force a
module into a slot or onto the backplane connectors. If you are having
problems installing a module without using excessive force, stop
immediately and contact Technical Services.
Never reach into a vacant shelf slot. Contact with the adjacent
modules or the connectors on the backplane could result in damage
to the equipment. Exposed circuitry could also constitute an energy
hazard.
Risk of electromagnetic disturbances!
Be careful not to damage the EMI shielding gasket on the module
faceplate edges when inserting it into the slot. Otherwise EMC
compliance cannot be achieved.
l Electrostatic Discharge Damage Prevention and Warning
l Installation Overview — SH12 and SH4R Shelves
l Handling Equipment Precautions and Guidelines
l Handling Equipment Precautions and Guidelines
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Installation plan
220 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
