Installing the PSM-AC4 in the SH4R
o
1+1 — Two PSM-AC4s (slots 35 and 36)
o
2+1 — Three PSM-AC4s (slots 35, 36, and 37)
3. Standing behind the SH4R, hold the PSM-AC4 upright with the faceplate toward you.
4. Insert the PSMinto the appropriate slot.
5. Gently apply pressure to the faceplate while pushing the module into the slot.
6. Push on the faceplate to fully seat the module. The module is completely inserted
when its faceplate is flush with the back plate of the SH4R.
7. When the PSM-AC4 is inserted completely, hand tighten the retaining screw to
prevent inadvertent dislodging.
8. Use a Torx T10 screwdriver to gently tighten the retaining screw as needed. Do not
overtighten.
9. Repeat this procedure for each PSM-AC4 that you want installed in the SH4R.
For improved cooling, install an appropriate slot cover in the empty PSM
slots.
l Electrostatic Discharge Damage Prevention and Warning
l PSM-AC4
l SH4R Shelf
l Installing the Slot Covers
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 219
