Adva FSP 3000 - Air Filter Pads; Front Cover Extension Kits

Air Filter Pads
l SH12 Shelf
l SH4R Shelf
l Clearance Requirements
l Side Air Covers
l Shelf Front Covers
l Front Cover Extension Kits
l Guide Rail Kits
l Supported Rack Requirements
1
if front cover is used
Air Filter Pads
Shelf Air Filter Pads Sales Item Number
SH12
F8/SA-AF-SH12:Contains 20 air filter pads - 10 for
each air filter (one below the modules and one in the
lower front cover)
1013800024-01
SH4R F8/SA-AF-SH4: Contains 10 air filter pads 1013800054-01
Table 56: Available Air Filter Pads
Always keep extra air filters on hand and order more when your supply
starts to run low.
l Replacing the Shelf Air Filter Pad
l Cooling and Airflow — SH12
l Cooling and Airflow — SH4R
Front Cover Extension Kits
The front cover extension increases the cabling space between the module faceplates
and the SH12 and SH4R shelf front cover.
If you plan to have a front cover installed on your FSP 3000 C shelf and
will be using cables with MPOconnectors, you must have the front cover
extension installed. To determine if your shelf rack/cabinet configuration
supports front covers and extensions, as well as more information about
accessory installation requirements, see Accessory Installation
Requirements.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 115
