Accessory Installation Requirements
Shelf
Accessory
Requirement
19-inch 23-inch
ETSI 300-
mm Depth
ETSI 600-
mm Depth
SH12 (cables w/LC
connectors)
Side air covers Required Required Removed Required
Upper front cover Optional Optional Optional Optional
Lower front cover Required Required Required Required
Front cover extension Optional Optional Optional Optional
SH4R (cables w/MPO
connectors)
Guide rail kit Required Required Not supported Not supported
Front cover Optional Optional Not supported Not supported
Front cover extension Required
1
Required
1
Not supported Not supported
SH4R (cables w/LC
connectors)
Guide rail kit Required Required Not supported Not supported
Front cover Optional Optional Not supported Not supported
Front cover extension Optional Optional Not supported Not supported
Table 54: Accessory Requirements — Open Rack Installations
Shelf
Accessory
Requirement
19-inch 23-inch
ETSI 300-mm
Depth
ETSI 600-mm
Depth
SH12 (cables
w/MPO
connectors)
Side air covers
l <400 mm
depth:
Removed
l >400 mm
depth:
Required
l <12 in.
depth:
Removed
l >16 in.
depth:
Required
Removed Required
Upper front cover Not supported Not supported Not supported Not supported
Lower front cover Required Required Required Required
Front cover
extension
N/A N/A N/A N/A
SH12 (cables
w/LC
connectors)
Side air covers
l 300 mm
depth:
Removed
l >400 mm
depth:
Required
l 12 in. depth:
Removed
l >16 in.
depth:
Required
Removed Required
Upper front cover Not supported Not supported Not supported Not supported
Lower front cover Required Required Required Required
Front cover
extension
Not supported Not supported Not supported Not supported
SH4R (cables
w/MPO
connectors)
Guide rail kit Required Required Not supported Not supported
Front cover Not supported Not supported Not supported Not supported
Front cover
extension
N/A N/A Not supported Not supported
SH4R (cables
w/LC
connectors)
Guide rail kit Required Required Not supported Not supported
Front cover Not supported Not supported Not supported Not supported
Front cover
extension
N/A N/A Not supported Not supported
Table 55: Accessory Requirements — Cabinet Installations
114 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
