Guide Rail Kits
Figure 25: Guide Rail Kit — F8/SA-GUIDE-SH4-S
Figure 26: Guide Rail Kit — F8/SA-GUIDE-SH4-L
The two guide rail brackets for the 23-inch rack installation are included in
the SH4R mounting bracket kit.
l Accessory Installation Requirements
l Supported Rack Requirements
l Mounting Bracket Kits
l Mounting the SH4R Shelf to a Rack
l SH4R Shelf
118 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
