ECM-2
Signals
l I2C (2 pins)
l Shelf detect (1 pin)
l Power (3V3 and ground, 2 pins)
1
Table 10: Specifications — Interconnect Ports
Even though some FSP 3000 C components use FireWire connectors for
interconnecting, neither the FireWire protocol nor pinning is supported.
Electrical connector type RJ-45
Receptacle type 8P8C
Data signal IEEE 802.3 100Mb/1G Ethernet
Cable type
l Unshielded for cable length: < 3 m
l Shielded (S/FTP) for cable length: 3 m to 100 m
Maximum link distance 100 m (328 ft)
Performance
l 10/100 Mb/s/1G Ethernet half/full duplex
l 10/100 Mb/s/1G Ethernet auto-negotiation can be
disabled
l Autosense
l Automatic MDI/MDI-X crossover capabilities
Compliance standards
l IEEE 802.3 10/100BASE-TX
l IEEE 802.3u
Table 11: Specifications — Management Ports
l Overview
l Features
l Ethernet Cables
l IEEE 1394 Interface Cable
1
one free pin
ECM-2
Overview 48
Features 49
Specifications 50
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 47
