ECM-2
l Specifications
l Port Pinouts
l Slot Numbers and Assignments — SH12
l Slot Numbers and Assignments — SH4R
l Traffic Module Support
Specifications
Electrical connector type RJ-45
Receptacle type 8P8C
Data signal IEEE 802.3 100Mb/1G Ethernet
Cable type
l Unshielded for cable length: < 3 m
l Shielded (S/FTP) for cable length: 3 m to 100 m
Maximum link distance 100 m (328 ft)
Performance
l 10/100 Mb/s/1G Ethernet half/full duplex
l 10/100 Mb/s/1G Ethernet auto-negotiation can be
disabled
l Autosense
l Automatic MDI/MDI-X crossover capabilities
Compliance standards
l IEEE 802.3 10/100BASE-TX
l IEEE 802.3u
Table 13: Specifications — External DCN/CLIPorts
Electrical connector type Mini-AB
Supported plugs
l Mini-A USB plug to act as master
l Mini-B USB plug to act as slave
Performance
l USBslave
l Provides only USBto RS-232 emulation
l Can be disabled
Compliance standards
l USB 2.0
l USB 1.1
Table 14: Specifications — Debugging Port
The serial port on the ECM-2 is an RJ-45 port and will have the
appropriate specifications.
50 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
