ECM-2
Parameter Value Notes
Power consumption 16 W Typical
19 W Maximum
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 12: General Information — ECM-2
Due to airflow shortcut, the ECM-2 needs to be reinserted or replaced
within less than one minute.
l Environmental Specifications
l MTBF Hours for FSP 3000 C Equipment
l SH12 Shelf
l SH4R Shelf
l Slot Numbers and Assignments — SH12
l Slot Numbers and Assignments — SH4R
l Cables
Features
l Handles the management plane, including support of all defined management
interfaces
l Controls all module internal management, as well as intrashelf communication with
other modules
l Handles inter-shelf communication within the NE
l Switches management and DCN traffic between the traffic modules and the ECM-2
and/or the external management ports on itself or on CEM
l Runs the OTN/WDM and GMPLS control planes
l Provides DB backup on removable internal flash memory
l Manages the PSMs
l Provides the following ports and indicators
o
One serial/RS-232 (RJ-45 connector) for connecting to the CLI
o
One 1G Ethernet (RJ-45 connector) for connecting to an external DCN (LEDs
indicate the rate and link status/activity of the connection)
o
One USB port used for debugging
o
Module LED indicates the equipment status, power, and module failures
o
Active/Standby LED (when redundant ECM-2s are supported)
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 49
