CEM-4
The CEM-4 is not redundant. When the CEM-4 is removed from the shelf:
l External management stops working
l All fans increase to maximum speed
l Some non-critical internal management of modules stops working
l Due to airflow shortcut, the CEM-4 needs to be reinserted or replaced in less than one
minute
l Airflow shortcut will lead to overheating and eventually a power shutdown of the shelf
l Environmental Specifications
l MTBF Hours for FSP 3000 C Equipment
l SH4R Shelf
l Slot Numbers and Assignments
l Passive Shelf Management
l Cables
Features
l Provides user management ports and indicators
o
Three 10/100/1000BASE-T Ethernet ports for management connectivity
o
Two management interconnect ports for passive shelf management
o
Shelf LEDs for Alarm, Shelf State, and Module Status
o
Network element (NE) status and alarm LEDs
l Assists the ECM-2 in shelf management and communication
l Controls the fans in the shelf
l Provides an Alarm Cut Off (ACO) button to reset the External I/O output signals and a
Lamp test button to test all LEDs in the shelf
l Displays shelf ID number on the LCD panel
l SH4R Shelf
l Specifications
l Port Pinouts
l Slot Numbers and Assignments
l FTM-4
Specifications
Electrical connector type FireWire (6-pins)
Cable type IEEE 1394 Interface Cable
Table 10: Specifications — Interconnect Ports
