Serial and Ethernet Cables
Item Description Sales Item Number Length
CBL/CAT6/RJ45/0500 1036006015 5 m (16.40 ft)
CBL/CAT6/RJ45/0300 1036006013 3 m (9.84 ft)
CBL/CAT6/RJ45/0100 1036006011 1 m (3.28 ft)
CABLE CAT5 2XRJ45 0500 1036006001 5 m (16.40 ft)
CABLE CAT5 2XRJ45 UTP 0100 1036006002 1 m (3.28 ft)
If you are providing your own Ethernet cables, the following table lists the types of
Ethernet cables that can be used.
Cable Category Level
Cable
Type
Frequency
Bandwidth
Uses
Cat 5e* (TIA/EIA-568-B.2) 4-pair STP up to 1GBE
100BASE-TX
10BASE-T
Cat 6* (ANSI/TIA/EIA-568-B.2-1) 4-pair STP up to 10GBE
1000BASE-T
100BASE-TX
10BASE-T
* Maximum segment distance = 100 meters (328 ft)
Category 6 (Cat 6) cables have been designed specifically for Gigabit Ethernet
applications. They deliver improved performance over standard Category 5e (Cat 5e)
cables. ADVA Optical Networking strongly recommends using Cat 6 cable for Gigabit
Ethernet over copper installations. Cat 6 is backward compatible with Cat 5e, Cat 5, and
Cat 3 cable standards. Cat 5e and Cat 6 cables support full duplex communication.
The eight wires inside the Cat 5e and Cat 6 cables are twisted into four wire pairs.
Pair Pins
Pair 1
4
5
Pair 2
3
6
Pair 3
1
2
Pair 4
7
8
Two male RJ-45 plugs (correctly referred to as male 8-position modular connectors)
terminate a Cat 5e and Cat 6 cable.
l Port Pinouts
l Handling Fiber-Optic Cables
l Cable Management Best Practices
l Electrostatic Discharge Damage Prevention and Warning
