Installing the SH4R Front Cover Extension
Figure 53: Extension Adapter Extended
4. Align the four screw holes, as shown in the above figure.
5. Use the Torx T10 screwdriver and the four screws to re-attach the extension adapter
to the front cover tab.
6. Repeat this procedure for all of the front cover tabs.
l Installation Overview — SH12 and SH4R Shelves
l Site Preparation Checklist
198 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
