FTM-4
A dirty air filter pad negatively influences cooling efficiency. Replace
dirty air filter pads at least once a year. ADVA Optical Networking
recommends replacing the air filter pad every 90 days. A software
timer is provided reminding filter pad replacement.
When a module needs to be taken out and/or replaced, it is important that this is done as
quickly as possible (<1 min) not to affect the thermal capability.
Parameter Value Notes
Sales item number 1042800054-01
Release introduced Release 1.1
Compatible shelves SH4R
Width 143 mm (5.6 in.)
Height 137 mm (5.4 in.)
Weight 1.1 kg (2.4 lbs)
Power consumption 20 W Typical
135 W Maximum
Power input from backplane 12 V
Ambient temperature 70°C (158°F) Maximum
–20°C (–4°F) Minimum
Fan rotation speed 11,500 rpm Maximum
5,200 rpm Minimum
Alarms reported
l Out-of-service disabled
l Temperature high
l Voltage abnormal
l Equipment fault
l Equipment removed
l Fan fault
l Fan abnormal
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 16: General Information — FTM-4
l Environmental Specifications
l MTBF Hours for FSP 3000 C Equipment
l Cooling and Airflow
l Slot Numbers and Assignments
l SH4R Shelf
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 55
