AM-S20H-2
Gain flatness <1.5 dBpp for gain set range: 19 dB to 35 dB
Tilt set range
l –2.0 dB to 0 dB
l Default: –1.0 dB
Tilt set resolution 0.1 dB
Minimum total input power –35 dBm
Maximum total input power +1 dBm (at gain = 19 dB)
Input LoL threshold –37 dBm
Maximum total output power +20.8 dBm
Noise figure (at default tilt) <6 dB at nominal gain = 27 dB
Output VOA set range
l 0 dB to 12 dB
l Default; 0 dB
Output VOA set resolution 0.1 dB
OPR TCA low threshold Provisionable, default: –38 dBm
OPR TCA high threshold Provisionable, default: +2 dBm
OPT TCA low threshold Provisionable, default: –19 dBm
OPT TCA high threshold Provisionable, default: +21 dBm
Table 27: Optical Specifications — High gain EDFA (20 dBm Output) for N-R to
C-T
Insertion loss 2 dB
LOS threshold –15 dBm
OPR TCA low threshold Provisionable, default: –15 dBm
OPR TCA high threshold Provisionable, default: +20 dBm
OPT TCA low threshold Provisionable, default: –15 dBm
OPT TCA high threshold Provisionable, default: +20 dBm
Table 28: Optical Specifications — Pre-amplifier Passive Path (C-R to N-T)
Type of gain stage EDFA
Supported Fault Management (FM)
End of Life (EOL), Abnormal (ANR),
Automatic Power Shutdown (APS),
OPT Limit
Supported Performance Monitoring (PM)
Gain Total, ASE Contribution, SES,
UAS, SES TCA H, UAS TCA H
Table 29: Gain Stage — N-R to C-T
Insertion loss Maximum: ≤1.5 dB
Passband 1600 nm to 1650 nm
Table 30: Aux-T to N-T Path
Insertion loss Maximum: ≤1.5 dB
Passband supported performance
monitoring (PM)
1600 nm to 1650 nm
Table 31: Aux-R to N-R Path
