MP-2B4CT
Supported fault
management (FM)
l PHY: LASER Fail, LASER On Delay, LOS-P, LOS
l OCh: Loss of Modem Sync
l OTU4V: LOF, LOM, BDI, DEG
l ODU4: OCI, LCK, BDI, DEG
Supported performance
monitoring (PM)
l PHY: OPT, OPR, OPT TCA H/L, OPR TCA H/L,
LASER Temp, LBC
l OCh: CDC, SNR, CFOT, DGD, CDC TCA H/L,
SNR TCA H, CFOT TCA H/L, DGD TCA H
l OTU4V: FEC corrected errors, FEC uncorrected
blocks, PreFEC BER, BBE, ES, SES, UAS, BBE
TCA H, ES TCA H, SES TCA H, UAS TCA H
l ODU4: BBE, ES, SES, UAS, BBE TCA H, ES TCA
H, SES TCA H, UAS TCA H
PMD tolerance 30 ps
CD tolerance Default:–60 ns/nm to +2 ns/nm
OSNR sensitivity 15% SD-
FEC absolute coding
12.5 dB
OSNR sensitivity 25% SD-
FEC absolute coding
12 dB
Table 42: 100G Network Interface
Protocols Proprietary 200G transport signal
Modulation 16 QAM
FEC
l 5 iteration 15% SD FEC
l 5 iteration 25% SD FEC
Supported fault
management (FM)
l PHY: LASER Fail, LASER On Delay, LOS-P, LOS
l OCh: Loss of Modem Sync
l OTUC2PA: LOF, LOM, TIM, DEG
l ODUC2PAjk: LOFLOM
l ODU4: OCI, LCK, BDI, TIM, DEG
Supported performance
monitoring (PM)
l PHY: OPT, OPR, OPT TCA H/L, OPR TCA H/L,
LASER Temp, LBC
l OCh: CDC, SNR, CFOT, DGD, CDC TCA H/L,
SNR TCA H, CFOT TCA H/L, DGD TCA H
l OTUC2PA: FEC corrected errors, FEC uncorrected
blocks, PreFEC BER, BBE, ES, SES, UAS, BBE
TCA H, ES TCA H, SES TCA H, UAS TCA H
l ODU4: BBE, ES, SES, UAS, BBE TCA H, ES
TCA H, SES TCA H, UAS TCA H
PMD tolerance 20 ps
CD tolerance –30,000 ps/nm to +2 ps/nm
Table 43: 200G Network Interface
