M13 Frame Overhead
X F1 C11 F0 C12 F0 C13 F1
X F1 C21 F0 C22 F0 C23 F1
P F1 C31 F0 C32 F0 C33 F1
P F1 C41 F0 C42 F0 C43 F1
M0 F1 C51 F0 C52 F0 C53 F1
M1 F1 C61 F0 C62 F0 C63 F1
M0 F1 C71 F0 C72 F0 C73 F1
X: Far-End Receive Failure
P: Even-Parity
M0: Multi-Framing Alignment 0
M1: Multi-Framing Alignment 1
F0,F1: Frame Alignment
Cxx: Bit stuffing indication
C-bit Frame Overhead
X F1 AIC F0 NA F0 FEAC F1
X F1 UDL F0 UDL F0 UDL F1
P F1 CP F0 CP F0 CP F1
P F1 FEBE F0 FEBE F0 FEBE F1
M0 F1 DL F0 DL F0 DL F1
M1 F1 UDL F0 UDL F0 UDL F1
M0 F1 UDL F0 UDL F0 UDL F1
AIC: Application Identification
NA: Network Application
FEAC: Far-End Alarm and Control
UDL: User Data Link
CP: C-bit Parity
FEBE: Far-End Block Error
DL: Data Link
Pattern type
Select the pattern to be inserted in the transmitted signal. Refer to Pattern
type in "E1 Setup and Status". Available patterns are:
Off
User [32] bit, User [2048] bit
PRBS 9 to PRBS 31
QRSS 20
Fox Pattern, Fox (CMA3000)
All 0's, All 1's
Alternating 1:1, Alternating 1:3, Alternating 1:7, Alternating 3:24
Touch 'Normal' or 'Inverse' pattern type.
Touching the 'ANSI standard' button will apply ANSI/IEEE 1007 recommended
Pattern type for 45 Mbit data rates (PRBS 23 Inverse).
User pattern
User pattern field is enabled if Pattern type is set to User [32] bit or User
[2084] bit. Touch the User pattern field and use the launched Pattern
Editor dialog box to define the user pattern. Depending on the selected
pattern type, different user pattern setup options will be available.
The length can be any length from 1 bit to 32 bits or from 1 bit to 2048 bits.
FEAC Code
When 'Frame type' is set to C-Bit, allows you to specify the six bits of FEAC
(Far-End Alarm and Control) channel code.
