Variable
Open the Pattern drop-down menu to select the relevant pattern.
FOX
5555
PRBS9 to PRBS31
HF TEST
CRPAT
JTPAT
SPAT
User 32 bit
If you select the User 32 bit pattern, a button appears with which you can
open the Pattern Editor dialog box.
The Variable allows you to set variables in the transmitted frames.
When ETH button in layer 2 is green.
When Custom button in layer 2 is green.
