8.3 Pass Through
CPRI/OBSAI Pass Through enables non-intrusive in-service monitoring. All traffic
received on a port is forwarded on the other port and vice versa. Traffic
between the two network DUT elements is monitored as illustrated below.
8.3.1 Ports Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports Setup screen, which also provides port status
information.
The setup options and status information related to the CPRI/OBSAI interface
are described in a separate section:
CPRI/OBSAI Setup and Status
8.3.2 Test Setup
8.3.2.1 Control
Refer to "Control" in the BERT section.
8.3.2.2 Thresholds
Refer to Thresholds of BERT section in "CPRI/OBSAI Applications".
8.3.3 Test Results
8.3.3.1 Summary
When you go to the test results of the CPRI Through application, the following
screen is displayed.
