Performance
Parameters
Delay
Stop function
Allows you to specify when the measurement ends. Select the relevant
option from the drop-down menu:
Manual stop: Stops the measurement immediately when you touch the
Stop button.
Stop at: Stops the measurement at the time specified in the Stop at
field on the right.
Duration: Performs the measurement for the duration of time specified
on the right.
Memory allocation
Allows you to specify how the measurement will be stored in the Network
Master's memory. Select the relevant option from the drop-down menu:
Use all storage: When Network Master's memory becames full of
measured data, the whole measurement is stopped.
Continuous: When Network Master's memory becames full of
measured data, the oldest records in that memory will be overwritten.
The Network Master's memory size (the file size of measurement results) is
64 Mbytes per one port.
Estimate of test duration
Contains an estimation of the time (in days, hours, minutes and seconds)
before the whole memory will be filled out by the test. During an ongoing
measurement, the estimate will be recalculated periodically.
If the CPRI/OBSAI signal is carried by OTN, the following parameters related to
OTN are available:
OTN
G.8201, M.2401 (M.2110)
Time period
15 minutes, 1 hour, 2 hours, 24 hours, 7 days
Allocation
Touching the Setup button launches the dialog box. Refer to Performance
Parameters in "OTN Application" .
8.2.2.2 Delay
Touching the Delay button in the navigation area displays the screen to set
threshold value.
Select the check box to enable the judgement using the threshold value.
If selecting check box, Port setup is changed as following:
Content: CPRI Link
Error insertion item: LCV
The check box will be cleared if Content has changed to other options.
Threshold
Allows you to specify a threshold value of Round Trip Delay in micro
seconds (μs).
8.2.2.3 Thresholds
Touching the Thresholds button in the navigation area displays the
following screen.
