Transport
This setting appears in case of BERT on OTN.
When you select the check box, you can enable alarm or error thresholds.
Interface
Fixed to OTN.
Evaluation item
Select the item to evaluate. If selecting other than Any Alarm or Error,
another menu appears.
Evaluation type
Select the relevant type.
Pass & fail threshold
Touch the left-hand number to set the lower limit for "Warning". Touch the
right-hand number to set the lower limit for "Fail". The lower limit of "Fail"
must be equal to or greater than the lower limit of "Warning" (defining a
"Within limits" range in between them).
9.2.3 Test Results
9.2.3.1 Summary
When you go to the test results of the Fibre Channel BERT application, the
following screen is displayed.
This screen contains a summary of the results of the Fibre Channel BERT
test. The information includes such things as number of pattern errors,
average and maximum disruption time, and number of exceeded
thresholds.
