Error generation
Alarm generation
WAN OH Capture
Frame Capture
TCP/UDP source and destination port
User-defined pattern at a defined offset
Adjustable thresholds
Utilization
Throughput
Errored frames
Collision rate
Unicast frames
Multicast frames
Broadcast frames
Pause frames
Fragmented frames
Undersized frames
Oversized frames
FCS errored frames
IFG violations (Ethernet 10/100/1000 Mbps)
Preamble violations
Difference between Tx and Rx
DHCP
Show source IP address assigned by DHCP.
Show current lease expire time.
Show IP addresses of primary and secondary DNS server when obtained
by DHCP.
For LAN
IFG (For 10/100/1000 Mbps), FCS, Preamble, Error symbol/block
Wrong IP checksum, fragmented IP, Wrong layer4 checksum
BERT Pattern error, BERT sequence error
For WAN
SDH:
A1A2, B1, B2, MS-REI, B3, HP-REI
SONET:
A1A2, B1, B2, REI-L, B3, REI-P
For LAN
No link
Local fault (For 10 Gbps)
Remote fault
For WAN
SDH:
LOS, LOF, OOF, MS-TIM, MS-AIS, MS-RDI, AU-AIS, AU-LOP, HP-TIM, HP-PLM,
HP-UNEQ, HP-RDI, LCD
SONET:
LOS, LOF, OOF, TIM-S, AIS-L, RDI-L, AIS-P, LOP-P, TIM-P, PLM-P, UNEQ-P,
RDI-P, LCD-P
Item
SOH/TOH: 64 Frames
POH: 64 Frames
Pathtrace:J0/J1/J2 (Displays in ascii characters)
Timing
Single
Repeat : Update period 1s
Buffer size
1, 2, 4, 8, 16, 32, 64, 128 MB
