Performance statistics
Maximum/Minimum/Average utilization
Maximum/Minimum/Average user and total throughput
Maximum/Minimum/Average frame rate
Maximum/Minimum/Average frame latency
Maximum/Minimum/Average packet jitter
Frame statistics
Total frames
Total valid frames
Unicast/multicast/broadcast frames
Pause frame
VLAN frame
MPLS frames
MPLS-TP frame
PBB frame
VLAN Max/Min level
MPLS Max/Min level
Fragmented frames
Oversized and Undersized frames
FCS errored frames
Error symboled frames (Excluding 10Gbps)
Code violation frames (For 10Gbps)
Collisions (10/100 Mbps half duplex)
Preamble Violations
IFG violations
Local Fault (For 10Gbps)
Remote Fault (For 10Gbps)
Last Received VLAN 1-8 (ID/Priority)
Last Received MPLS 1-8 (Label/Priority/TTL)
B-Tag, I-tag (ID/Priority)
Burst statistics
Disabled in case of the OTN client.
Total frames in burst
Good/Bursted frames
Number of Bursts
Maximum/Minimum/Average burst size
Frame distribution statistics
Total valid/good frames
64 - 127 byte frames
128 - 255 byte frames
256 - 511 byte frames
512 - 1023 byte frames
1024 - 1518 byte frames
Total number of jumbo frames
Maximum/Minimum/Average frame size
Filters
Up to 8 filter conditions can be defined. Each condition can filter on:
IP or MAC source address
IP or MAC destination address
Broadcast address
IEEE OUI value
Encapsulation type
VLAN ID
VLAN tag priority
MPLS
MPLS-TP source/destination MAC
PBB source/destination MAC
PBB I-tag/B-tag
