Version 6.2 171 February 2011
SIP User's Manual 3. Web-Based Management
Parameter Description
Web: Dest IP Group
ID
EMS: Destination IP
Group ID
The IP Group to where you want to route the call. The SIP INVITE message
is sent to the IP address defined for the Proxy Set ID associated with the IP
Group.
Notes:
If you select an IP Group, you do not need to configure a destination IP
address. However, if both parameters are configured in this table, the
INVITE message is sent only to the IP Group (and not the defined IP
address).
If the destination IP Group is of type USER, the device searches for a
match between the Request-URI (of the received INVITE) to an AOR
registration record in the device's database. The INVITE is then sent to the
IP address of the registered contact.
If the parameter AlwaysUseRouteTable is set to 1 (see ''Configuring IP
Groups'' on page 119), then the Request-URI hos
t name in the INVITE
message is set to the value defined for the parameter 'Dest. IP Address'
(above); otherwise, if no IP address is defined, it is set to the value of the
parameter 'SIP Group Name' (defined in the 'IP Group' table).
This parameter is used as the 'Serving IP Group' in the 'Account' table for
acquiring authentication user/password for this call (see ''Configuring
Account Table'' on page 133).
For defining Proxy Set ID's, see ''Configuring Proxy Sets Table'' on page
126.
Dest SRD The SRD to where you want to route the call. The actual destination is
defined by the Proxy Set associated with the SRD. This allows you to route
the call to a specific SIP Media Realm and SIP Interface.
To configure SRD's, see Configuring SRD Table on page 114.
IP Profile ID IP Profile ID (see ''Configuring IP Profiles'' on page 143) assigned to this IP
destination call. This allows you to assign numerous configuration attributes
(e.g., voice codes) per routing rule.
Status
Read-only field displaying the Quality of Service of the destination IP address:
n/a = Alternative Routing feature is disabled.
OK = IP route is available.
Ping Error = No ping to IP destination; route is unavailable.
QoS Low = Poor QoS of IP destination; route is unavailable.
DNS Error = No DNS resolution (only when domain name is used instead
of an IP address).
Web/EMS: Charge
Code
Optional Charge Code assigned to the routing rule. For configuring Charge
Codes, see Configuring Charge Codes Table on page 181.
Not
e: This parameter is applicable only to FXS interfaces.
