SIP User's Manual 12. Configuration Parameters Reference
12 Configuration Parameters Reference
The device's VoIP functionality (not data-routing functionality) configuration parameters,
default values, and their descriptions are documented in this section.
Parameters and values enclosed in square brackets ([...]) represent the ini file parameters
and their enumeration values; parameters not enclosed in square brackets represent their
corresponding Web interface and/or EMS parameters.
Note: Some parameters are configurable only through the ini file.
12.1 Networking Parameters
This subsection describes the device's networking parameters.
12.1.1 VoIP Multiple Network Interfaces and VLAN Parameters
The IP network interfaces and VLAN parameters are described in the table below.
Table 12-1: IP Network Interfaces and VLAN Parameters
Parameter Description
Web: Multiple Interface Table
EMS: IP Interface Settings
[InterfaceTable]
This ini file table parameter configures the Multiple Interface table for
configuring the IP addresses of the voice and/or data functionalities and
logical IP addresses. The format of this parameter is as follows:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
[\InterfaceTable]
For example:
InterfaceTable 0 = 0, 0, 192.168.85.14, 16, 0.0.0.0, 1, Management;
InterfaceTable 1 = 2, 0, 200.200.85.14, 24, 0.0.0.0, 200, Control;
InterfaceTable 2 = 1, 0, 211.211.85.14, 24, 211.211.85.1, 211, Media;
InterfaceTable 0 = 0, 0, 192.168.85.14, 16, 0.0.0.0, 1, Management;
InterfaceTable 1 = 2, 0, 200.200.85.14, 24, 0.0.0.0, 200, Control;
InterfaceTable 2 = 1, 0, 211.211.85.14, 24, 211.211.85.1, 211, Media;
The above example, configures three network interfaces (OAMP,
Control, and Media).
Notes:
 For this ini file table parameter to take effect, a device reset is
required.
 Up to 12 logical IP addresses with associated VLANs can be defined
(indices 0-11). However, only up to 8 interfaces can be used for
media RTP traffic (assigned to a Media Realm in the 'SIP Media
