AudioCodes Mediant 800 MSBG - Table 3-31: ISDN Supp Services Table Parameters; Figure 3-101: ISDN Supp Services Table

SIP User's Manual 192 Document #: LTRT-12804
Mediant 800 MSBG
¾ To configure BRI supplementary services:
1. Open the 'ISDN Supp Services Table' page (Configuration tab > VoIP menu > GW
and IP to IP submenu > Digital Gateway submenu > ISDN Supp Services).
Figure 3-101: ISDN Supp Services Table Page
2. Configure the parameters as described in the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, see ''Saving Configuration'' on page 336.
Table 3-31: I
SDN Supp Services Table Parameters
Parameter Description
Phone Number The telephone extension number for the BRI endpoint.
Module The BRI module number to which the BRI extension pertains.
Port The port number (on the BRI module) to which the BRI extension is
connected.
User ID User ID for registering the BRI endpoint to a third-party softswitch for
authentication and/or billing.
User Password User password for registering the BRI endpoint to a third-party
softswitch for authentication and/or billing.
Note: For security, the password is displayed as an asterisk (*).
Caller ID Caller ID name of the BRI extension (sent to the IP side).
The valid value is a string of up to 18 characters.
Presentation Restricted Determines whether the BRI extension sends its Caller ID information
to the IP when a call is made.
 [0] Allowed = The device sends the string defined in the 'Caller ID'
field when this BRI extension makes a Tel-to-IP call.
 [1] Restricted = The string defined in the 'Caller ID' field is not sent.
Caller ID Enabled Enables the receipt of Caller ID.
 [0] Disabled = The device does not send Caller ID information to
the BRI extension.
 [1] Enabled = The device sends Caller ID information to the BRI
extension
