Version 6.2 631 February 2011
SIP User's Manual 9. VoIP Networking Capabilities
9.5.2.4 Troubleshooting the Routing Table
When adding a new static routing rule, the added rule passes a validation test. If errors are
found, the routing rule is rejected and is not added to the IP Routing table. Failed routing
validations may result in limited connectivity (or no connectivity) to the destinations
specified in the incorrect routing rule. For any error found in the Routing table or failure to
configure a routing rule, the device sends a notification message to the Syslog server
reporting the problem.
Common routing rule configuration errors may include the following:
The IP address specified in the "Gateway" column is unreachable from the interface
specified in the "Interface" column.
The same destination is defined in two different routing rules.
More than 30 routing rules were defined.
Note: If a routing rule is required to access OAMP applications (for remote
management, for instance) and this route is not configured correctly, the route
is not added and the device is not accessible remotely. To restore
connectivity, the device must be accessed locally from the OAMP subnet and
the required routes be configured.
9.5.3 Setting Up VoIP Networking
9.5.3.1 Using the Web Interface
The Web interface is a convenient user interface for configuring the device's network
configuration.
9.5.3.2 Using the ini File
When configuring the network configuration using the ini File, use a textual presentation of
the Interface and Routing Tables, as well as some other parameters. The following shows
an example of a full network configuration, consisting of all the parameters described in
this section:
; *** TABLE InterfaceTable ***
[ InterfaceTable ]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
InterfaceTable 0 = 0, 10, 192.168.0.2, 16, 192.168.0.1, 501, Mgmt;
InterfaceTable 1 = 5, 10, 10.32.174.50, 24, 10.32.174.1, 2012,
MediaCntrl;
InterfaceTable 2 = 1, 10, 10.33.174.50, 24, 10.33.174.1, 2013, Media1;
InterfaceTable 3 = 2, 10, 10.34.174.50, 24, 10.34.174.1, 2014, Cntrl1;
[ \InterfaceTable ]
; Routing Table Configuration:
[ StaticRouteTable ]
