AudioCodes Mediant 800 MSBG - Digit Collection and Dial Plan Parameters

SIP User's Manual 750 Document #: LTRT-12804
Mediant 800 MSBG
Parameter Description
used for the received DTMF packets. If negotiation isn't
used, this payload type is used for receive and for transmit.
[ReplaceNumberSignWithEscape
Char]
Determines whether to replace the number sign (#) with the
escape character (%23) in outgoing SIP messages for Tel-to-
IP calls.
 [0] Disable (default)
 [1] Enable = All number signs #, received in the dialed
DTMF digits are replaced in the outgoing SIP Request-URI
and To headers with the escape sign %23.
Notes:
 This parameter is applicable only if the parameter
IsSpecialDigits is set 1.
 This parameter is applicable only to analog interfaces.
Web: Special Digit Representation
EMS: Use Digit For Special DTMF
[UseDigitForSpecialDTMF]
Defines the representation for ‘special’ digits (‘*’ and ‘#’) that
are used for out-of-band DTMF signaling (using SIP
INFO/NOTIFY).
 [0] Special = Uses the strings ‘*’ and ‘#’ (default).
 [1] Numeric = Uses the numerical values 10 and 11.
12.12.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 12-36: Digit Collection and Dial Plan Parameters
Parameter Description
Web/EMS: Dial Plan Index
[DialPlanIndex]
Determines the Dial Plan index to use in the external Dial Plan
file. The Dial Plan file is loaded to the device as a *.dat file
(converted using the DConvert utility). The Dial Plan index can be
defined globally or per Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1
denotes PLAN2, and so on. The default is -1, indicating that no
Dial Plan file is used.
Notes:
 If this parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If this parameter is configured to select a Dial Plan index from
an external Dial Plan file, the device first attempts to locate a
matching digit pattern in the Dial Plan file, and if not found,
then attempts to locate a matching digit pattern in the Digit
Map rules configured by the DigitMapping parameter.
 This parameter is applicable also to ISDN with overlap dialing.
 For E1 CAS MFC-R2 variants (which don't support terminating
digit for the called party number, usually I-15), this parameter
and the DigitMapping parameter are ignored. Instead, you can
define a Dial Plan template per trunk using the parameter
CasTrunkDialPlanName_x (or in the 'Trunk Settings' page).
 This parameter can also be configured per Tel Profile, using
