Version 6.2 183 February 2011
SIP User's Manual 3. Web-Based Management
¾ To configure the FXO parameters:
1. Open the 'FXO Settings' page (Configuration tab > VoIP menu > GW and IP to IP
submenu > Analog Gateway submenu > FXO Settings).
Figure 3-93: FXO Settings Page
2. Configure the parameters as required.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, see ''Saving Configuration'' on page 336.
3.3.2.11.5.5 Configuring Authentication
The 'Authentication' page defines a user name and password for authenticating each
device port. Authentication is typically used for FXS interfaces, but can also be used for
FXO interfaces.
Notes:
• For configuring whether authentication is performed per port or for the
entire device, use the parameter AuthenticationMode. If authentication is
for the entire device, the configuration on this page is ignored.
• If either the user name or password fields are omitted, the port's phone
number and global password (using the Password parameter) are used
instead.
• After you click the Submit button, the password is displayed as an
asterisk (*).
• You can also configure Authentication using the ini file table parameter
Authentication (see SIP Configuration Parameters).
