SIP User's Manual 9. VoIP Networking Capabilities
The figure depicts a typical configuration featuring in which the device is configured with
three network interfaces for:
Operations, Administration, Maintenance, and Provisioning (OAMP) applications
Call Control applications
Media
The Multiple Interfaces scheme allows the configuration of up to 12 different IP addresses,
each associated with a unique VLAN ID. The configuration is performed using the Multiple
Interface table, which is configurable using the ini file, Web, and SNMP interfaces.
9.5.1.1 Overview of Multiple Interface Table
The Multiple Interfaces scheme allows you to define up to 12 different IP addresses and
VLANs in a table format, as shown below:
Table 9-1: Multiple Interface Table
Index
Mode
Application Interface IP Address
Prefix
Length
Default
Gateway
VLAN
ID
Interface
Name
0 OAMP IPv4 10.31.174.50 16 0.0.0.0 4 ManagementIF
1 Control IPv4 10.32.174.50 16 0.0.0.0 5 ControlIF
2 Media IPv4 10.33.174.50 16 10.33.0.1 6 Media1IF
3 Media IPv4 10.34.174.50 16 0.0.0.0 7 Media2IF
4 Media IPv4 10.35.174.50 16 10.35.0.1 8 Media3IF
5 Media IPv4 10.36.174.50 16 0.0.0.0 9 Media4IF
6 Media IPv4 10.37.174.50 16 0.0.0.0 10 Media5IF
7 Media IPv4 10.38.174.50 16 0.0.0.0 11 Media6IF
8 Media IPv4 10.39.174.50 16 10.39.0.1 12 Media7IF
9 Media IPv4 10.40.174.50 16 10.40.0.1 13 Media8IF
10
Media &
Control
IPv4 10.41.174.50 16 0.0.0.0 14 MediaCtrl9IF
11 Media IPv4 10.42.174.50 16 0.0.0.0 15 Media10IF
12 Media IPv4 10.43.174.50 16 10.43.0.1 16 Media11IF
13 Media IPv4 10.44.174.50 16 0.0.0.0 17 Media12IF
14
Media &
Control
IPv4 10.45.174.50 16 10.45.0.1 18 Media13IF
Complementing this network configuration is the On-Board Ethernet Switch configuration.
This allows configuring the VLAN IDs accessible through each physical port, as well as the
Native VLAN ID of each physical port. The On-Board Ethernet Switch configuration is
described in LAN Switch on page 292. In addition,
Layer3 (DiffServ) and Layer 2 (VLAN
priority) Quality of Service parameters are also configurable.
