Dell PowerConnect 5324 Command Line Interface Reference Manual

Clock 103
Default Configuration
No servers are defined.
Command Mode
Global Configuration mode
User Guidelines
• Up to 8 SNTP servers can be defined.
• Use the
sntp unicast client enable Global Configuration mode command to enable
predefined unicast clients globally.
• To enable polling you should also use the
sntp unicast client poll Global Configuration mode
command for global enabling.
• Polling time is determined by the
sntp client poll timer Global Configuration mode
command.
• If multiple servers are added then the updates applied are determined by the following:
Unicast Server updates take precedence, followed by Anycast and then Broadcast.
Examples
The following example configures the device to accept Network Time Protocol (NTP) traffic from
the server on 192.1.1.1.
show clock
The show clock User EXEC mode command displays the time and date from the system clock.
Syntax
show clock [detail]
• detail — Shows timezone and summertime configuration.
Default Configuration
This command has no default configuration.
Command Mode
User EXEC mode
Console (config)# sntp server 192.1.1.1

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
