Dell PowerConnect 5324 Command Line Interface Reference Manual

Ethernet Configuration Commands 125
Default Configuration
Automatic crossover is enabled
Command Mode
Interface Configuration (Ethernet) mode
User Guidelines
• Mdix Auto: All possibilities to connect a PC with cross OR normal cables are supported and
are automatically detected.
•
Mdix ON : It is possible to connect to a PC only with a normal cable and to connect to
another switch ONLY with a cross cable.
• If MDIX is set to "no mdix", the device works opposite from the "MDIX On" behavior. With
this setting you can only use either an ethernet standard cross-over cable to connect to a PC,
or an ethernet standard cable to connect to another switch.
Example
In the following example, automatic crossover is enabled on g5.
back-pressure
The back-pressure Interface Configuration mode command enables Back Pressure on a given
interface. To disable Back Pressure, use the
no form of this command.
Syntax
back-pressure
no back-pressure
Default Configuration
Back Pressure is disabled.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• Back Pressure will operate only if duplex mode is set to half.
Console(config)# interface ethernet g5
Console(config-if)# mdix auto

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
