Dell PowerConnect 5324 Command Line Interface Reference Manual

Address Table Commands 89
show bridge multicast address-table
The show bridge multicast address-table Privileged EXEC mode command displays multicast
MAC address table information.
Syntax
show bridge multicast address-table [ vlan vlan-id ] [ address mac-multicast-address | ip-
multicast-address
] [ format ip | mac ]
•
vlan_id —A VLAN ID value.
•
mac-multicast-address —A MAC multicast address in the format of xx:xx:xx:xx:xx:xx.
•
ip-multicast-address— An IP multicast address.
•
format — Multicast address format. Can be ip or mac . If format is unspecified, the default
is
mac .
Default Configuration
This command has no default configuration.
Command Mode
Privileged EXEC mode
User Guidelines
• There are no user guidelines for this command.
Example
In this example, multicast MAC address table information is displayed.
Console# show bridge address-table count
Capacity: 8192
Free: 8084
Used: 108
Static addresses: 2
Dynamic addresses: 97
Internal addresses: 9

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
