Dell PowerConnect 5324 Command Line Interface Reference Manual

270 Spanning-Tree Commands
www.dell.com | support.dell.com
Command Mode
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example configures the maximum number of hops that a packet travels in an MST
region before it is discarded to 10.
spanning-tree mst port-priority
The spanning-tree mst port-priority Interface Configuration mode command configures port
priority for the specified MST instance. To return to the default configuration, use the
no form of
this command.
Syntax
spanning-tree mst instance-id port-priority priority
no spanning-tree mst instance-id port-priority
• instance-ID — ID of the spanning tree instance. (Range: 1-15)
•
priority — The port priority. (Range: 0 - 240 in multiples of 16)
Default Setting
The default port priority for IEEE Multiple Spanning Tree Protocol (MSTP) is 128.
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidlines
• There are no user guidelines for this command.
Example
The following example configures the port priority of port g1 to 142.
Console (config) # spanning-tree mst max-hops 10
Console(config)# interface ethernet g1
Console(config-if)# spanning-tree mst 1 port-priority 142

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
