Dell PowerConnect 5324 Command Line Interface Reference Manual

Command Groups 37
SSH Commands
spanning-tree link-type Overrides the default link-type setting . Interface
Configuration
spanning-tree pathcost
method
Sets the default path cost method. Global
Configuration
spanning-tree bpdu Defines BPDU handling when spanning tree is
disabled on an interface.
Global
Configuration
clear spanning-tree
detected-protocols
Restarts the protocol migration process on all
interfaces or on the specified interface.
Privileged User
EXEC
show spanning-tree Displays spanning tree configuration. Privileged User
EXEC
spanning-tree mst mstp-
rstp
Configure the switch to convert STP/RSTP packets to
MSTP instances.
Global
Configuration
Spanning-tree guard root Enables root guard on all the spanning tree instances
on that interface.
Interface
Configuration
Command Group Description Access Mode
ip ssh port Specifies the port to be used by the SSH server. Global
Configuration
ip ssh server Enables the device to be configured from a SSH
server.
Global
Configuration
crypto key generate dsa Generates DSA key pairs. Global
Configuration
crypto key generate rsa Generates RSA key pairs. Global
Configuration
ip ssh pubkey-auth Enables public key authentication for incoming
SSH sessions.
Global
Configuration
crypto key pubkey-chain ssh Enters SSH Public Key-chain configuration mode. Global
Configuration
user-key Specifies which SSH public key is manually
configured and enters the SSH public key-string
configuration command.
SSH Public Key
key-string Manually specifies a SSH public key. SSH Public Key
show ip ssh Displays the SSH server configuration. Privileged User
EXEC
show crypto key mypubkey Displays the SSH public keys stored on the device. Privileged User
EXEC

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
