Dell PowerConnect 5324 Command Line Interface Reference Manual

RMON Commands 225
RMON Commands
show rmon statistics
The show rmon statistics User EXEC mode command displays RMON Ethernet Statistics.
Syntax
show rmon statistics { ethernet interface number | port-channel port-channel-number }
•
interface —Valid Ethernet port.
•
port-channel-number —Valid port-channel trunk index.
Default Configuration
This command has no default configuration.
Command Mode
User EXEC mode
User Guidelines
• The following RMON Groups are supported - Ethernet Statistics (Group1), History (Group
2), Alarms (Group 3) and Events (Group 4).
Example
The following example displays RMON Ethernet Statistics for port g1.
Console# show rmon statistics ethernet g1
Port g1
Dropped: 8
Octets: 878128 Packets: 978
Broadcast: 7 Multicast: 1
CRC Align Errors: 0 Collisions: 0
Undersize Pkts: 0 Oversize Pkts: 0
Fragments: 0 Jabbers: 0
64 Octets: 98 65 to 127 Octets: 0
128 to 255 Octets: 0 256 to 511 Octets: 0
512 to 1023 Octets: 491 1024 to 1518 Octets: 389

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
