Dell PowerConnect 5324 Command Line Interface Reference Manual

348 VLAN Commands
www.dell.com | support.dell.com
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example forbids adding VLANs number 234 till 256, to g8.
map protocol protocols-group
The map protocol protocols-group VLAN Configuration mode command maps a protocol to a
protocol group. Protocol groups are used for protocol-based VLAN assignment. To delete a protocol
from a group, use the no form of this command.
Syntax
map protocol protocol [ encapsulation ] protocols-group group
no map protocol protocol encapsulation
• protocol —The protocol is a 16 or 40 bits protocol number or one of the following names,
ip-arp or ipx . The protocol number is in Hex format (Range: 0600 - FFFF).
•
encapsulation —One of the following values: ethernet , rfc1042 or llcOther . If no option is
indicated the default is
ethernet .
•
group —Protocol group number (Range: 1 - 2147483647).
Default Configuration
This command has no default configuration.
Command Mode
VLAN Configuration mode
User Guidelines
There are no user guidelines for this command
Example
The following example maps protocol ip-arp to the group named "213".
Console (config)# interface ethernet g8
Console (config-if)# switchport forbidden vlan add 234-256
Console (config)# vlan database
Console (config-vlan)# map protocol ip-arp protocols-group 213

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
