Dell PowerConnect 5324 Command Line Interface Reference Manual

Port Channel Commands 201
Port Channel Commands
interface port-channel
The interface port-channel Global Configuration mode command enters the interface
configuration mode of a specific port-channel.
Syntax
interface port-channel port-channel-number
• port-channel-number —A valid port-channel trunk index.
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode
User Guidelines
• Eight aggregated links can be defined with up to 8 member ports per port channel.Turning off
auto-negotiation of an aggregate link may, under some circumstances, make it non-
operational. If the other side has auto-negotiation turned on, it may re-synchronize all
members of the aggregated link to half-duplex operation, and may, as per the standards, set
them all to inactive.
Example
The following example enters the context of port-channel number 1.
interface range port-channel
The interface range port-channel Global Configuration mode command enters the interface
configuration mode to configure multiple port-channels.
Syntax
interface range port-channel { port-channel-range | all }
•
port-channel-range —List of port-channels to configure. Separate non-consecutive port-
channels with a comma and no spaces. A hyphen designates a range of port-channels.
•
all —All the channel-ports.
Console (config)# interface port-channel 1

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
