Dell PowerConnect 5324 Command Line Interface Reference Manual

SNMP Commands 249
• priv —Specifies authentication of a packet with encryption. Applicable only to SNMP
Version 3 security model.
•
context name — Specifies context of packet.
•
read readview — A string that is the name of the view that enables you only to view the
contents of the agent. If unspecified, all the objects except of the community-table and
SNMPv3 user and access tables are available. (Range: Up to 30 characters)
•
write writeview — A string that is the name of the view that enables you to enter data and
configure the contents of the agent. If unspecified, nothing is defined for the write view.
(Range: Up to 30 characters)
•
notify notifyview — A string that is the name of the view that enables you to specify an
inform or a trap. If unspecified, nothing is defined for the notify view. (Range: Up to 30
characters)
Default configuration
No group entry exists.
Command Mode
Global configuration
User Guidelines
• The Router context is translated to "" context in the MIB.
Example
The following example configures a new Simple Network Management Protocol (SNMP) group or
a table that maps SNMP users to SNMP views
snmp-server user
To configure a new SNMP Version 3 user, use the snmp-server user global configuration
command. To remove a user, use the no form of the command.
Syntax
snmp-server user username groupname [ remote engineid-string ] [ auth - md5 password | auth-
sha
password | auth - md5-key md5-des-keys | auth - sha-key sha-des-keys ]
no snmp-server user username [ remote engineid-string ]
•
username — The name of the user on the host that connects to the agent. (Range: Up to
30 characters)
Console (config)# snmp-server group user-group v3 priv read
user-view

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
