Dell PowerConnect 5324 Command Line Interface Reference Manual

IP Addressing Commands 165
Command Mode
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Examples
The following example defines a default domain name of www.dell.com.
ip name-server
The ip name-server Global Configuration mode command sets the available name servers. To
remove a name server, use the
no form of this command.
Syntax
ip name-server server-address [ server-address2 … server-address8 ]
no ip name-server [ server-address1 … server-address8 ]
•
server-address— IP addresses of the name server. Up to 8 servers can be defined in one
command or by using multiple commands.
Default Configuration
No name server addresses are specified.
Command Mode
Global Configuration mode
User Guidelines
• The preference of the servers is determined by the order they were entered.
• Up to 8 servers can be defined.
Examples
The following example sets the available name server.
ip host
The ip host Global Configuration mode command defines a static host name-to-address mapping
in the host cache. To
remove the name-to-address mapping, use the no form of this command.
Console (config)# ip domain-name www.dell.com
Console (config)# ip name-server 176.16.1.18

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
