Dell PowerConnect 5324 Command Line Interface Reference Manual

QoS Commands 213
Example
The following example sets queue 4, 3 to be expedite queues.
show qos interface
The show qos interface User EXEC mode command displays interface QoS data.
Syntax
show qos interface [ ethernet interface-number | queuing ]
•
ethernet interface-number —Ethernet port number.
•
queuing —Displays the queue strategy (WRR or EF), the weight for WRR queues, the
CoS to queue map and the EF priority.
Default Configuration
There is no default configuration for this command.
Command Mode
User EXEC mode
User Guidelines
If no keyword is specified with the show qos interface command, the port QoS mode (DSCP
trusted, CoS trusted, untrusted), default CoS value, attached to the port, attached to the
interface are displayed. If a specific interface is not specified, the information for all interfaces
is displayed.
Examples
The following example displays output from the show qos interface g1 queueing command.
Console (config)# priority-queue out num-of-queues 2

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
