Dell PowerConnect 5324 Command Line Interface Reference Manual

272 Spanning-Tree Commands
www.dell.com | support.dell.com
Syntax
spanning-tree mst configuration
Default Setting
This command has no default configuration.
Command Mode
Global Configuration mode
User Guidelines
• All devices in an MST region must have the same VLAN mapping, configuration revision
number, and name.
Example
The following example configures an MST region.
instance (mst)
The instance MST Configuration mode command maps VLANS to an MST instance.
Syntax
instance instance-id {add | remove} vlan vlan-range
• instance-ID — ID of the MST instance (Range: 1- 8).
•
vlan-range — VLANs to be added to or removed from the specified MST instance. To
specify a range of VLANs, use a hyphen. To specify a series of VLANs, use a comma.
(Range: 1-4094).
Default Setting
VLANs are mapped to the common and internal spanning tree (CIST) instance (instance 0).
Command Modes
MST Configuration mode
User Guidelines
• All VLANs that are not explicitly mapped to an MST instance are mapped to the common
and internal spanning tree (CIST) instance (instance 0) and cannot be unmapped from the
CIST.
Console(config)# spanning-tree mst configuration
Console(config-mst) # instance 1 add vlan 10-20
Console(config-mst) # name region1
Console(config-mst) # revision 1

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
